Modern wastewater technology means performance and economy: The EasyClean free Basic Direct grease separator is an efficient answer to the challenge of wastewater disposal in large kitchens and food processing businesses that is as safe as it is reliable. Made of hard-wearing polymer, it is still fully operational even decades after installation.
Unpleasant or even noxious odours during disposal? They are a thing of the past with the EasyClean free Basic Direct grease separator! The cost-effective alternative for a high level of convenience: Thanks to the permanently installed direct disposal pipe, the contents of the tank can be disposed of completely without odour nuisance. Cleaning and maintenance are nonetheless not a problem: The inside of the grease separator is accessed conveniently through the two covers.
100 % corrosion-free – 20-year guarantee
Our grease separators are made of polyethylene. That makes them resistant to aggressive fatty acids and they are therefore particularly durable. Trust in KESSEL quality: In addition to the statutory provision, we provide a 20-year warranty with regard to the leak tightness, fitness for purpose and structural stability of tanks and upper sections.
EasyClean free Basic Direct
Flow direction, left
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.10DL | 100 mm | 2 | 100 mm | 94002.10DL | Show |
94004.10DL | 100 mm | 4 | 100 mm | 94004.10DL | Show |
94007.10DL | 150 mm | 7 | 150 mm | 94007.10DL | Show |
94010.10DL | 150 mm | 10 | 150 mm | 94010.10DL | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.21DL | 100 mm | 2 | 100 mm | 94002.21DL | Show |
94004.21DL | 100 mm | 4 | 100 mm | 94004.21DL | Show |
94007.21DL | 150 mm | 7 | 150 mm | 94007.21DL | Show |
94010.21DL | 150 mm | 10 | 150 mm | 94010.21DL | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.12DL | 100 mm | 2 | 100 mm | 94002.12DL | Show |
94004.12DL | 100 mm | 4 | 100 mm | 94004.12DL | Show |
94007.12DL | 150 mm | 7 | 150 mm | 94007.12DL | Show |
94010.12DL | 150 mm | 10 | 150 mm | 94010.12DL | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.32DL | 100 mm | 2 | 100 mm | 94002.32DL | Show |
94004.32DL | 100 mm | 4 | 100 mm | 94004.32DL | Show |
94007.32DL | 150 mm | 7 | 150 mm | 94007.32DL | Show |
94010.32DL | 150 mm | 10 | 150 mm | 94010.32DL | Show |
Flow direction, right
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.10DR | 100 mm | 2 | 100 mm | 94002.10DR | Show |
94004.10DR | 100 mm | 4 | 100 mm | 94004.10DR | Show |
94007.10DR | 150 mm | 7 | 150 mm | 94007.10DR | Show |
94010.10DR | 150 mm | 10 | 150 mm | 94010.10DR | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.21DR | 100 mm | 2 | 100 mm | 94002.21DR | Show |
94004.21DR | 100 mm | 4 | 100 mm | 94004.21DR | Show |
94007.21DR | 150 mm | 7 | 150 mm | 94007.21DR | Show |
94010.21DR | 150 mm | 10 | 150 mm | 94010.21DR | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.12DR | 100 mm | 2 | 100 mm | 94002.12DR | Show |
94004.12DR | 100 mm | 4 | 100 mm | 94004.12DR | Show |
94007.12DR | 150 mm | 7 | 150 mm | 94007.12DR | Show |
94010.12DR | 150 mm | 10 | 150 mm | 94010.12DR | Show |
| Inlet nominal size (DN) | Nominal size (NS) | Outlet nominal size (DN) | Item no. | ||
|---|---|---|---|---|---|
94002.32DR | 100 mm | 2 | 100 mm | 94002.32DR | Show |
94004.32DR | 100 mm | 4 | 100 mm | 94004.32DR | Show |
94007.32DR | 150 mm | 7 | 150 mm | 94007.32DR | Show |
94010.32DR | 150 mm | 10 | 150 mm | 94010.32DR | Show |
